產品詳情
主要技術參數 MAIN SPECIFICATIONS
|

					玻璃加工厚度

			 |
			Glass thickness |
				 3-21mm  |

|

					玻璃回轉直徑

			 |
			Maximum diameter |
				 100-2100mm  |

|

					斜邊角度

			 |
			Bevel degree |
				 0-20°  |

|

					最大斜邊寬

			 |
			Max.Width of bevel |
				 35mm  |

|

					工作臺轉速

			 |
			Rotating speed of working table |

					0.8-4 r/min

			 |

|

					獨立轉盤轉速

			 |
			Rotating speed of independent turnplate |
				 1.2-6r/min  |

|

					總功率

			 |
			Power |

					 26W

			 |

|

					總重量

			 |
			Weight |

					1000kg

			 |

|

					外形尺寸

			 |
			Land occupation |

					1300×1300×1700mm

			 |
